Place of Origin: Fujian, China (Mainland)
Brand Name: JINGGONG
Model Number: JG608S
Condition: New
Moving Type: Wheel Excavator
Bucket capacity: 0.2~0.3m3
Maximum Digging Height: 5800mm
Maximum Digging Depth: 3380mm
Machine Weight: 6000Kg, 6000KG
Max Digging Radius: 6000mm
Engine Type: SL4100ABK
Rated Power: 47Kw/ 55Hp
Length*width*height(mm):5500*2100*2850
Running Speed(Low/High): 9/36Km/h
Full Circle Swinging Time: 5.5s
Gradeability: 30 degree
Pressure to Ground: 52Kpa
RANGE OF OPERATION Boom length 3030mm Arm length 1860mm Max digging reach 6000mm Max digging depth 3380mm Max digging force 45kn Max digging height 5800mm Max dumping height 4300mm Min platform tail turning radius 1775mm DIMENSIONS Distance from the arm to rotate machine 3620mm (Length*width*height)travel position 5500*2100*2850mm Ground clearance of counterweight 1060mm Min ground clearance 200mm TECH PERFORMANCE AND SPECIFICATION Angle of rotation 360° Machine weight 6000kg Engine model SL/4100ABK/498BPG Hydraulic system working pressure 19.5Mpa Nominal capacity 43kw/55hp/48kw Rate of travel speed 9/36km/h Max hauling force 60KN Walking speed 36km/h Grade Climbing ability 58%/30° Full circle swinging time 5.5s Volume of bucket 0.2-0.3m3 Revolution overdrive pressure 11Mpa Fqt fuel quantity 4≥L/H Capacity of the fuel tank 130L Capacity of the hydraulic tank 110LPackaging & Delivery
Delivery Detail: 7-15 days after receiving deposit
RANGE OF OPERATION | |
Boom length | 3030mm |
Arm length | 1860mm |
Max digging reach | 6000mm |
Max digging depth | 3380mm |
Max digging force | 45kn |
Max digging height | 5800mm |
Max dumping height | 4300mm |
Min platform tail turning radius | 1775mm |
DIMENSIONS | |
Distance from the arm to rotate machine | 3620mm |
(Length*width*height)travel position | 5500*2100*2850mm |
Ground clearance of counterweight | 1060mm |
Min ground clearance | 200mm |
TECH PERFORMANCE AND SPECIFICATION | |
Angle of rotation | 360° |
Machine weight | 6000kg |
Engine model | SL/4100ABK/498BPG |
Hydraulic system working pressure | 19.5Mpa |
Nominal capacity | 43kw/55hp/48kw |
Rate of travel speed | 9/36km/h |
Max hauling force | 60KN |
Walking speed | 36km/h |
Grade Climbing ability | 58%/30° |
Full circle swinging time | 5.5s |
Volume of bucket | 0.2-0.3m3 |
Revolution overdrive pressure | 11Mpa |
Fqt fuel quantity | 4≥L/H |
Capacity of the fuel tank | 130L |
Capacity of the hydraulic tank | 110L |
