Place of Origin: Fujian, China (Mainland)
Brand Name: JINGGONG
Model Number: JG85-6S
Condition: New
Moving Type: Wheel Excavator
Bucket capacity: 0.4m3
Maximum Digging Height: 6400mm
Maximum Digging Depth: 4000mm
Machine Weight: 8000Kg, 8000KG
Max Digging Radius: 7100mm
Engine Type: YC4108
Rated Power: 53Kw/ 72Hp
Max Hauling Force: 80 KN
Length*width*height(mm):6450*2250*2950
Running Speed(Low/High): 40Km/h
Full Circle Swinging Time: 5.5s
RANGE OF OPERATION Boom length 4000mm Arm length 2100mm Max digging reach 7100mm Max digging depth 4000mm Max digging force 60kn Max digging height 6400mm Max dumping height 4850mm Min platform tail turning radius 2250mm DIMENSIONS Distance from the arm to rotate machine 4180mm (Length*width*height)travel position 6450*2250*2950mm Ground clearance of counterweight 1150mm Min ground clearance 280mm TECH PERFORMANCE AND SPECIFICATION Angle of rotation 360° Machine weight 8000kg Engine model YC4108 Hydraulic system working pressure 19.5Mpa Nominal capacity 53KW/72HP Rate of travel speed 40km/h Max hauling force 80KN Walking speed 40km/h Grade Climbing ability 58%/30° Full circle swinging time 5.5s Volume of bucket 0.4m3 Revolution overdrive pressure 11Mpa Fqt fuel quantity 6≥L/H Capacity of the fuel tank 160L Capacity of the hydraulic tank 130LPackaging & Delivery
Delivery Detail: 7-15 days after receiving deposit
RANGE OF OPERATION | |
Boom length | 4000mm |
Arm length | 2100mm |
Max digging reach | 7100mm |
Max digging depth | 4000mm |
Max digging force | 60kn |
Max digging height | 6400mm |
Max dumping height | 4850mm |
Min platform tail turning radius | 2250mm |
DIMENSIONS | |
Distance from the arm to rotate machine | 4180mm |
(Length*width*height)travel position | 6450*2250*2950mm |
Ground clearance of counterweight | 1150mm |
Min ground clearance | 280mm |
TECH PERFORMANCE AND SPECIFICATION | |
Angle of rotation | 360° |
Machine weight | 8000kg |
Engine model | YC4108 |
Hydraulic system working pressure | 19.5Mpa |
Nominal capacity | 53KW/72HP |
Rate of travel speed | 40km/h |
Max hauling force | 80KN |
Walking speed | 40km/h |
Grade Climbing ability | 58%/30° |
Full circle swinging time | 5.5s |
Volume of bucket | 0.4m3 |
Revolution overdrive pressure | 11Mpa |
Fqt fuel quantity | 6≥L/H |
Capacity of the fuel tank | 160L |
Capacity of the hydraulic tank | 130L |
