Product Details

Quick Details

Delivery Detail:	30 days after receiving deposit

RANGE OF OPERATION
Boom length	4200mm
Arm length	2000mm
Max digging reach	7200mm
Max digging depth	4200mm
Max digging force	90kn
Max digging height	7500mm
Max dumping height	5400mm
Min platform tail turning radius	2250mm
DIMENSIONS
Distance from the arm to rotate machine	3620mm
(Lengthwidthheight)travel position	720024003000mm
Ground clearance of counterweight	1220mm
Min ground clearance	230mm

TECH PERFORMANCE AND SPECIFICATION
Angle of rotation	360°
Machine weight	12500kg
Engine model	Cummins 4BTA3.9-C125
Hydraulic system working pressure	19.5Mpa
Nominal capacity	90kw/120HP
Rate of travel speed	25km/h
Max hauling force	120KN

Grade Climbing ability	58%/30°
Full circle swinging time	5.5s
Volume of bucket	0.5m3
Revolution overdrive pressure	11Mpa
Fqt fuel quantity	8≥L/H
Capacity of the fuel tank	200L
Capacity of the hydraulic tank	200L
